| UOM | EA | Seal Material | Fluorocarbon |
| Actuation Type | Electrical, Manual | Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN |
| Configuration | Normally Closed, Partially Pressure Compensated | Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Power Consumption | 18, 28 W | Wire Mesh Screen Included | No |
| Variation of Closing Point | N/A | Maximum Inlet Pressure Rating | 210 bar |
| Flow Direction | Bi-directional | Function | Proportional Flow Control/Regulator |
| Connection Size | N/A | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Variation of Opening Point | 17% of Input Signal, 21% of Input Signal | Operating Temperature | -15 to +400 °F |
| Flow Rate | 8, 9.5 Gal/min | Cavity Size | C10-2 |
| Minimum Operating Temperature | -15 °F | Override Functionality | Infinite Control |
| Operation Type | Solenoid operated, Manually operated | Installation Torque | 22 lb-ft |
| Division | Hydraulic Systems Division | Coil Nut Tightening Torque | 3 lb-ft |
| Weight | 0.12 kg | Maximum Operating Pressure | 3000 psi |
| Configuration | Normally Closed, Partially Pressure Compensated | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Flow Rate Accuracy | +/- 5% | Actuation Type | Electrical, Manual |
| Body Material | N/A | Seal Material | Fluorocarbon |
| Valve Material | All parts steel. All operating parts hardened steel | Maximum Flow Rate | 8, 9.5 Gal/min |
| Minimum Pressure Differential | N/A psi | Leak Rate | 378 @ 3000 PSI (210 BAR) cm3/min |
| Hysteresis | < 10% | Maximum Operating Temperature | +204 °C |
| Division | Hydraulic Cartridge Systems Division | Frequency | 100-400 Hz |
| Coil Type | 5/8" Super Coil | Connection Type | N/A |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | | |
