| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical | Configuration | Normally Closed, Pressure Compensated |
| Flow Rate | 2 GAL/MIN, 7.5 L/MIN | Operation Type | Solenoid operated |
| Division | Hydraulic Systems Division | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Flow Rate Accuracy | Up to 20% | Weight | 0.08 kg |
| Maximum Operating Pressure | 3000 psi | Body Material | N/A |
| Installation Torque | 27 Nm | Maximum Operating Temperature | +250 °F |
| Seal Material | Nitrile | Minimum Pressure Differential | 10.3 bar |
| Leak Rate | 570 @ 3000 PSI (210 BAR) cm3/min | Maximum Inlet Pressure Rating | 3000 psi |
| Hysteresis | < 10% | Valve Material | All parts steel. All operating parts hardened steel |
| Connection Type | N/A | Frequency | 100-400 Hz |
| Division | Hydraulic Cartridge Systems Division | Coil Type | 1/2" Super Coil Low Watt (CCS) |
| Maximum Flow Rate | 7.5 L/min | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Power Consumption | 14 W | Current | Max: 1.15 @ 12 VDC, 0.58 @ 24 VDC A |
| Minimum Operating Temperature | -34 °C | Cavity Size | C08-3 |
| Connection Size | N/A | Variation of Closing Point | N/A |
| Function | Proportional Flow Control/Regulator | Flow Direction | Top to Side (3 - 2) |
| Wire Mesh Screen Included | Yes | Flow Rate | 7.5 L/min |
| Actuation Type | Electrical | Configuration | Normally Closed, Pressure Compensated |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Operating Temperature | -30 to +250 °F |
| Variation of Opening Point | 25% of Input Signal | Coil Nut Tightening Torque | 4.1 Nm |
| Override Functionality | N/A | | |
