| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical | Flow Rate | 2.5 GAL/MIN, 9.5 L/MIN |
| Configuration | Normally Open, Pressure Compensated | Configuration | Normally Open, Pressure Compensated |
| Coil Nut Tightening Torque | 4.1 Nm | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Variation of Opening Point | N/A | Operating Temperature | -30 to +250 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Actuation Type | Electrical |
| Override Functionality | N/A | Flow Rate | 9.5 L/min |
| Operation Type | Solenoid operated | Coil Type | 1/2" Super Coil Low Watt (CCS) |
| Connection Type | N/A | Division | Hydraulic Systems Division |
| Installation Torque | 27 Nm | Weight | 0.08 kg |
| Maximum Operating Pressure | 3000 psi | Flow Rate Accuracy | Up to 20% |
| Body Material | N/A | Seal Material | Nitrile |
| Valve Material | All parts steel. All operating parts hardened steel | Maximum Inlet Pressure Rating | 3000 psi |
| Minimum Pressure Differential | 10.3 bar | Hysteresis | < 3% |
| Connection Size | N/A | Frequency | 100-400 Hz |
| Division | Hydraulic Cartridge Systems Division | Leak Rate | 570 @ 3000 PSI (210 BAR) cm3/min |
| Maximum Flow Rate | 2.5 Gal/min | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Operating Temperature | +121 °C | Minimum Operating Temperature | -34 °C |
| Current | Max: 1.15 @ 12 VDC, 0.58 @ 24 VDC A | Cavity Size | C08-3 |
| Power Consumption | 14 W | Variation of Closing Point | 75% of Input Signal |
| Flow Direction | Top to Side (3 - 2) | Function | Proportional Flow Control/Regulator |
| Wire Mesh Screen Included | No | | |
