| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical | Configuration | Normally Closed, Pressure Compensated |
| Flow Rate | 30, 36 L/MIN | Minimum Pressure Differential | 200, 300 psi |
| Maximum Inlet Pressure Rating | 3000 psi | Hysteresis | 7% |
| Seal Material | Nitrile | Valve Material | All parts steel. All operating parts hardened steel |
| Maximum Operating Temperature | +250 °F | Connection Type | N/A |
| Frequency | 100-400 Hz | Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min |
| Division | Hydraulic Cartridge Systems Division | Coil Type | 5/8" Super Coil |
| Maximum Flow Rate | 8, 9.5 Gal/min | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Power Consumption | 18, 28 W | Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Minimum Operating Temperature | -34 °C | Cavity Size | 3X |
| Connection Size | N/A | Variation of Closing Point | N/A |
| Flow Direction | Top to Side (3 - 2) | Function | Proportional Flow Control/Regulator |
| Wire Mesh Screen Included | No | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Flow Rate | 8, 9.5 Gal/min | Actuation Type | Electrical |
| Configuration | Normally Closed, Pressure Compensated | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Operating Temperature | -34 to +121 °C | Variation of Opening Point | 25% of Input Signal |
| Coil Nut Tightening Torque | 3 lb-ft | Override Functionality | N/A |
| Operation Type | Solenoid operated | Division | Hydraulic Systems Division |
| Flow Rate Accuracy | Up to 20% | Body Material | N/A |
| Weight | 0.13 kg | Maximum Operating Pressure | 210 bar |
| Installation Torque | 30 Nm | | |
