| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical | Flow Rate | 9.5 GAL/MIN, 36 L/MIN |
| Configuration | Normally Open, Pressure Compensated | Coil Nut Tightening Torque | 4.1 Nm |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Maximum Operating Pressure | 210 bar |
| Configuration | Normally Open, Pressure Compensated | Operating Temperature | -30 to +250 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Actuation Type | Electrical |
| Variation of Opening Point | N/A | Flow Rate | 36 L/min |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Connection Type | N/A |
| Operation Type | Solenoid operated | Installation Torque | 30 Nm |
| Weight | 0.28 lb | Flow Rate Accuracy | +/- 7% |
| Division | Hydraulic Systems Division | Body Material | N/A |
| Seal Material | Nitrile | Valve Material | All parts steel. All operating parts hardened steel |
| Minimum Pressure Differential | 200 psi | Maximum Inlet Pressure Rating | 210 bar |
| Connection Size | N/A | Division | Hydraulic Cartridge Systems Division |
| Frequency | 100-400 Hz | Maximum Flow Rate | 9.5 Gal/min |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | 7% |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Maximum Operating Temperature | +121 °C |
| Cavity Size | 3X | Minimum Operating Temperature | -34 °C |
| Override Functionality | N/A | Current | Max: 2.33 @ 12 VDC, 1.17 @ 24 VDC A |
| Power Consumption | 28 W | Variation of Closing Point | 25% of Input Signal |
| Wire Mesh Screen Included | No | Function | Proportional Flow Control/Regulator |
| Flow Direction | Top to Side (3 - 2) | | |
