| UOM | EA | Seal Material | Nitrile |
| Actuation Type | Electrical, Manual | Flow Rate | 9.5 GAL/MIN, 36 L/MIN |
| Configuration | Normally Open, Pressure Compensated | Wire Mesh Screen Included | Yes |
| Variation of Closing Point | 25% of Input Signal | Flow Direction | Top to Side (3 - 2) |
| Function | Proportional Flow Control/Regulator | Seal Material | Nitrile |
| Connection Size | N/A | Maximum Inlet Pressure Rating | 3000 psi |
| Variation of Opening Point | N/A | Flow Rate | 36 L/min |
| Minimum Operating Temperature | -30 °F | Current | Max: 2.33 @ 12 VDC, 1.17 @ 24 VDC A |
| Cavity Size | 3X | Override Functionality | Infininte Control |
| Power Consumption | 28 W | Weight | 0.28 lb |
| Installation Torque | 30 Nm | Body Material | N/A |
| Division | Hydraulic Systems Division | Flow Rate Accuracy | Up to 20% |
| Operation Type | Solenoid operated, Manually operated | Operating Temperature | -34 to +121 °C |
| Maximum Operating Pressure | 210 bar | Configuration | Normally Open, Pressure Compensated |
| Coil Nut Tightening Torque | 4.1 Nm | Actuation Type | Electrical, Manual |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Maximum Flow Rate | 9.5 Gal/min | Division | Hydraulic Cartridge Systems Division |
| Valve Material | All parts steel. All operating parts hardened steel | Maximum Operating Temperature | +250 °F |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | 7% |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Minimum Pressure Differential | 200 psi |
| Frequency | 100-400 Hz | Connection Type | N/A |
| Coil Type | 5/8" Super Coil High Watt (CAP) | | |
