24W337

Manufacturer: Graco

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU 24W337

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Working Pressure	3600 psi
Weight	59 lb	Fluid Outlet Size	1 Inch
Sound Power Level	77.2 dB(A)	Fluid Outlet Thread Type	NPT
Maximum Air Inlet Pressure	100 psi	Air Inlet Thread Gender	Female
Air Inlet Thread Type	NPT	Fluid Inlet Type	NPT
Fluid Inlet Thread Type	NPT	Model	GT 750
Pump Ratio	36:1	Maximum Continuous Cycle Rate	60 CPM
Fluid Outlet Thread Gender	Female	Air Motor Effective Diameter	7.5 Inch
Sound Pressure Level	70.5 dB(A)	Maximum Air Consumption	130 SCFM
Air Inlet Size	0.5 Inch	Output Per Cycle	180 Cubic cm
