27KAIW21EVX

Manufacturer: Parker

Availability:	Backordered
Partner Available:	Backordered

SKU 27KAIW21EVX

$593.18/each

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Outside Diameter	27 mm
For Fluid Type	Breathing Air	Material	316L Stainless Steel
Connection Type	Female, BSPP	Maximum Flow Rate	2400 lpm (Air)
Materials of Construction	Stainless Steel AISI 316L	Standard	RoHS
Operation Type	Sleeve	Flow Rate	2400 lpm (Air)
Valve Included	Yes	Length	56.5 mm
Type	Pneumatic Quick Couplings	Application	Food & Beverages
Compatible Fitting	Series 27 Plug	Connection Size	G 1/2 Inch
Function	Single Shut-Off	Technology	Pneumatics
Shape	Straight	Flow Diameter	10 mm (Nominal)
Valve Type	High Flow Valve	Coupling Half	Coupler
Plating Type	Without Surface Treatment	Minimum Operating Temperature	-15 °C
Version	Single Shut-Off	Sleeve Material	Brass
Hex Size	24 mm	Seal Material	FKM
Interchange Type	European Profile	Maximum Operating Temperature	392 °F
Product Series	Series 27
