| UOM | EA | Seal Material | Fluorocarbon |
| Flow Rate | 16 GAL/MIN, 60 L/MIN | Actuation Type | Electrical, Manual |
| Configuration | Normally Closed, Pressure Compensated | Body Material | N/A |
| Actuation Type | Electrical | Configuration | Normally Closed, Pressure Compensated |
| Flow Rate Accuracy | +/- 50% of Input Signal | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Coil Nut Tightening Torque | 3 lb-ft | Weight | 0.31 lb |
| Maximum Operating Pressure | 210 bar | Variation of Opening Point | 17% Nominal Amperage, 21% Nominal Amperage |
| Operating Temperature | -26 to +204 °C | Flow Rate | 16 Gal/min |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Regulated Flow Rate | 26, 30 L/min | Frequency | 100-400 Hz |
| Coil Type | 5/8" Super Coil | Maximum Flow Rate | 60 L/min |
| Connection Type | N/A | Division | Hydraulic Systems Division |
| Installation Torque | 30 Nm | Operation Type | Solenoid operated |
| Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 | Function | Proportional Flow Control/Regulator |
| Connection Size | N/A | Maximum Inlet Pressure Rating | 3000 psi |
| Hysteresis | 7% | Minimum Pressure Differential | 13.8, 20.7 bar |
| Maximum Operating Temperature | +400 °F | Valve Material | All parts steel. All operating parts hardened steel |
| Seal Material | Fluorocarbon | Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min |
| Override Functionality | N/A | Minimum Operating Temperature | -15 °F |
| Current | 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A | Cavity Size | 4C |
| Power Consumption | 18, 28 W | | |
