| UOM | EA | Flow Rate | 11, 12, 13 GAL/MIN, 41.6, 45.4, 49.2 L/MIN |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Configuration | Normally Closed, Normally Open, Selector |
| Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR | Actuation Type | Electrical, Manual |
| Seal Material | Nitrile | Division | Hydraulic Systems Division |
| Operating Temperature | -30 to +250 °F | Flow Rate | 11, 12, 13 Gal/min |
| Input Voltage | 85% of rated voltage at 72°F (20°C) min | Actuation Type | Electrical, Manual |
| Maximum Flow Rate | 49.2 L/min | Maximum Operating Pressure | 3000 psi |
| Maximum Operating Temperature | +250 °F | Minimum Operating Temperature | -34 °C |
| Body Material | N/A | Seal Material | Nitrile |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Weight | 0.59 kg |
| Mounting Type | Screw in cartridge valve | Operation Type | Solenoid operated, Manually operated |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Configuration | Normally Closed, Normally Open, Selector |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Function | 3-way |
| Coil Type | 1" DS Coil | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Leak Rate | 82 @ 3000 PSI (210 BAR) cm3/min | Cavity Size | C16-3 |
| Valve Material | All parts steel. All operating parts hardened steel | Installation Torque | 54 Nm |
| Maximum Inlet Pressure Rating | 210 bar | Override Functionality | Push Type |
| Response Time | 90-100 ms | Coil Nut Tightening Torque | 4.1 Nm |
