| UOM | EA | Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR |
| Seal Material | D-Ring (Standard) | Actuation Type | Electrical |
| Configuration | Normally Closed, Normally Open, Selector | Flow Direction | 2-1 De-energized, 3-1 Energized |
| Flow Rate | 4, 4.5 GAL/MIN, 15, 17 L/MIN | Division | Hydraulic Systems Division |
| Operating Temperature | -35 to +200 °F | Flow Rate | 4. 4.5 Gal/min |
| Input Voltage | 85% of rated voltage at 72°F (20°C) min | Actuation Type | Electrical |
| Maximum Flow Rate | 17 L/min | Maximum Operating Pressure | 350 bar |
| Maximum Operating Temperature | +93 °C | Minimum Operating Temperature | -37 °C |
| Body Material | N/A | Seal Material | D-Ring (Standard) |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Weight | 0.19 kg |
| Mounting Type | Screw in cartridge valve | Operation Type | Solenoid operated |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Configuration | Normally Closed, Normally Open, Selector |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Function | 3-way |
| Coil Type | 5/8" Super Coil | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Leak Rate | 160 @ 5000 PSI (350 BAR) cm3/min | Cavity Size | C10-3 |
| Valve Material | All parts steel. All operating parts hardened steel | Installation Torque | 69-75 Nm |
| Maximum Inlet Pressure Rating | 350 bar | Override Functionality | N/A |
| Response Time | 50-100 ms | Coil Nut Tightening Torque | 7-10 Nm |
