| UOM | EA | Seal Material | D-Ring (Standard) |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Normally Open, Selector |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Maximum Inlet Pressure Rating | 3600 PSI, 250 BAR |
| Flow Rate | 2.25, 3.5 GAL/MIN, 8.4, 13.2 L/MIN | Actuation Type | Electrical, Manual |
| Body Material | N/A | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Coil Nut Tightening Torque | 5-7 lb-ft | Maximum Operating Pressure | 250 bar |
| Weight | 0.13 kg | Configuration | Normally Closed, Normally Open, Selector |
| Flow Rate | 2.25, 3.5 Gal/min | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Operating Temperature | -35 to +200 °F | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Flow Rate | 3.5 Gal/min | Coil Type | 1/2" Super Coil |
| Division | Hydraulic Systems Division | Operation Type | Solenoid operated, Manually operated |
| Installation Torque | 23-27 lb-ft | Maximum Inlet Pressure Rating | 250 bar |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Function | 3-way |
| Maximum Operating Temperature | +93 °C | Leak Rate | 120 @ 3600 PSI (250 BAR) cm3/min |
| Seal Material | D-Ring (Standard) | Valve Material | All parts steel. All operating parts hardened steel |
| Mounting Type | Screw in cartridge valve | Override Functionality | Pull and Release |
| Minimum Operating Temperature | -35 °F | Cavity Size | C08-3 |
| Input Voltage | 85% of rated voltage at 72°F (20°C) min | Response Time | 50 ms |
