787ST Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker’s GlobalCore 787ST hose provides 5,000 psi (35 MPa) constant working pressure in all sizes. ½ ISO 18752 minimum bend radius. Flex impulse tested providing a hose superior in both performance and service life. Meets ISO 18752 performance specification.

View as Grid List

Sort by

Display per page

SKU	Availability	Partner Available	Price	UOM	Mating Fitting Series	Working Pressure	Inner Diameter	Material	Parker Group	Inch/Metric	Parker Division	Inner Diameter	Inner Diameter Inch/mm	Material	Application	Working Pressure Range	Hose Category	Operating Temperature	Trade Name	Mating End Fitting Series	Specification	Minimum Bend Radius	Hose Pressure Range	Series	Distinct Properties	ISO 18752 Performance	Working Pressure
787ST-10-RL	Backordered	Backordered	$35.38/foot	FT	77	5,000 psi (35 MPa)	0.625 Inch	Rubber	Fluid Connector	Inch	Hose Products	0.625 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +257°F (-40°C to +125°C)	GlobalCore	77	ISO 18752	4 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	DC	5,000 psi (35 MPa)
787ST-24-BX	Backordered	Backordered	$161.50/foot	FT	77	5,000 psi (35 MPa)	1.5 Inch	Rubber	Fluid Connector	Inch	Hose Products	1.5 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +257°F (-40°C to +125°C)	GlobalCore	77	ISO 18752	10 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	DC	5,000 psi (35 MPa)
787ST-4-BX	Backordered	Backordered	$9.46/foot	FT	43	5,000 psi (35 MPa)	0.25 Inch	Rubber	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +212°F (-40°C to +100°C)	GlobalCore	43	ISO 18752	2 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	AC	5,000 psi (35 MPa)
787ST-4-RL	Backordered	Backordered	$7.64/foot	FT	43	5,000 psi (35 MPa)	0.25 Inch	Rubber	Fluid Connector	Inch	Hose Products	0.25 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +212°F (-40°C to +100°C)	GlobalCore	43	ISO 18752	2 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	AC	5,000 psi (35 MPa)
787ST-6-BX	Backordered	Backordered	$10.68/foot	FT	43	5,000 psi (35 MPa)	0.375 Inch	Rubber	Fluid Connector	Inch	Hose Products	0.375 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +212°F (-40°C to +100°C)	GlobalCore	43	ISO 18752	2 1/2 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	AC	5,000 psi (35 MPa)
787ST-6-RL	Backordered	411 in stock	$11.22/foot	FT	43	5,000 psi (35 MPa)	0.375 Inch	Rubber	Fluid Connector	Inch	Hose Products	0.375 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +212°F (-40°C to +100°C)	GlobalCore	43	ISO 18752	2 1/2 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	AC	5,000 psi (35 MPa)
787ST-8-RL	Backordered	6 in stock	$40.31/foot	FT	43	5,000 psi (35 MPa)	0.5 Inch	Rubber	Fluid Connector	Inch	Hose Products	0.5 Inch	Inch	Rubber	Hydraulic	> 5000 PSI (345 bar)	Hydraulic Industry Standard	-40°F to +257°F (-40°C to +125°C)	GlobalCore	43	ISO 18752	3 1/2 Inch	High	787ST	Super Tough Cover Constant Pressure 5000 PSI	DC	5,000 psi (35 MPa)
