95UM-10X1.75-0100 - PU Tubing

Flexible Polyurethane Tubing -95U/95UM Series offers the greatest flexibility and kink resistance along with exceptional abrasion resistance of any rubber or thermoplastic tubing.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 14 days
Partner Available:	32 in stock

SKU 95UM-10X1.75-0100

$2.18/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Product Type	Metric
Standard Pack Qty (ft)	100	Color	Natural
Order Size	10MM	Maximum Operating Pressure	170
Compatible Fitting	Fast & Tite®	Maximum Operating Temperature	180
Division	Parflex Division	Tube Inside Diameter	0.256
Tube Material	Polyurethane	Media	Air
Minimum Burst Pressure	510	Application	Instrumentation
Minimum Operating Temperature	-40	Tube Outside Diameter	10
Wall Thickness	1.75 MM	Material	Polyurethane
Max. Operating Pressure	170 psi 11.7 Bar	Max. Operating Temperature	180 °F 82 °C
Outside Diameter	10 MM	Media	Air, Water
Inside Diameter	0.256 Inch 60.5 MM	Min. Burst Pressure	510 psi 35.1 Bar
Min. Operating Temperature	-40 °C -40 °F	Parker Group	Fluid Connector
Parker Division	Tubing
