Air Operated Directional Control Valve - D31DA, D31VA Series

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Parker’s D31*A directional control valves are suitable for manifold or subplate mounting. These valves conform to NFPA’s D03, CETOP 3 mounting patterns.

Markets:
• Entertainment Automation
• Factory Automation
• Lumber & Wood
• Machine Tools
• Marine
• Material Handling
• Miscellaneous Industrial
• Miscellaneous Manufacturing
• Miscellaneous Processing
• Molding
• Oil & Gas
• Other Natural Resources
• Packaging Machinery
• Plastic Packaging
• Power Generation
• Primary Metal Refining/Process
• Printing and Marking Equipment
• Rubber & Tire Processing
• Vehicle Assembly Facilities

Features/Benefits:
• Mounting bolts below center line of spool minimizes spool binding
• Five chamber style eliminates pressure spikes in tubes, increasing valve life
• High pressure & flow ratings provide increased performance options in a compact valve

Applications:
• Suitable for general hydraulic applications

View as Grid List

Sort by

Display per page

SKU	Availability	Partner Available	Price	UOM	Mounting Type	Maximum Operating Pressure	Maximum Flow Rate	Size	Valve Type	Division	Spool Position	Maximum Flow Rate	Size	Maximum Operating Temperature	Options	Seal Material	Pilot Inlet / Drain Locations	Minimum Operating Temperature	Mounting Type	Spool Code	Body Material	Actuation Type	Weight	Maximum Operating Pressure
D31VA004C4N7	Backordered	Backordered	$2,112.60/each	EA	Subplate	5000 PSI	Up to 40 GPM depending on spool	NFPA D05H, CETOP 5	Air Operated Directional Control Valve	Hydraulic Valve Systems Division	Spring Centered	40 Gal/min	CETOP 5	140 °F	Pilot Choke Meter-out	Nitrile	Internal Pilot / Internal Drain	-4 °F	Subplate	P Port Blocked	Gray Iron	Hydraulic Pressure	12.7 lb	345 bar
D31VA020B4N	Backordered	Backordered	POR	EA	Subplate	5000 PSI	Up to 40 GPM depending on spool	NFPA D05H, CETOP 5	Air Operated Directional Control Valve	Hydraulic Valve Systems Division	Single Operator	40	NFPA D05H	140	n/a	Nitrile	Internal Pilot / Internal Drain	-4	Subplate	4-Way	Gray Iron	Hydraulic Pressure	12	5000
D31VA020D4N	Backordered	Backordered	$1,617.00/each	EA	Subplate	5000 PSI	Up to 40 GPM depending on spool	NFPA D05H, CETOP 5	Air Operated Directional Control Valve	Hydraulic Valve Systems Division	Double Operator	40 Gal/min	CETOP 5	140 °F	n/a	Nitrile	Internal Pilot / Internal Drain	-4 °F	Subplate	Closed Crossover	Gray Iron	Hydraulic Pressure	12.7 lb	345 bar
D31VA020D4V7	Backordered	Backordered	$2,147.88/each	EA	Subplate	5000 PSI	Up to 40 GPM depending on spool	NFPA D05H, CETOP 5	Air Operated Directional Control Valve	Hydraulic Valve Systems Division	Detent	40 Gal/min	NFPA D05H	140 °F	Pilot Choke Meter-out	Fluorocarbon	Internal Pilot / Internal Drain	-4 °F	Subplate	2-Position	Gray Iron	Hydraulic Pressure	12.7 lb	5000 psi
