D11AA2A - Aluminum Pumps – D Series

Parker’s Aluminum Pump D Series fixed displacement gear pump offers high performance and high power density due to its aluminum construction.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 54 days
Partner Available:	19 in stock

SKU D11AA2A

$470.11/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Rotation	ClockWise
Shaft Seal Material	NBR	Porting	7/8 -14 x 3/4 -16 UNF Straight Thread - Side
Shaft Type	1/2 Dia. Keyed	Mounting Style	2-Bolt SAE "AA"
Available Accessories	n/a	Pressure Relief Setting (psig)	n/a
Overall Length (inch)	3.47 (88.14 mm)	Pump Displacement (cu in/rev)	D11: .262 (4.29 cc/rev)
Division	Pump & Motor Division	Maximum Flow Rate	n/a
For Fluid Type	Phosphate-esther (w/FPM seals)	Displacement	0.641 inch3/rev
Operating Pressure	up to 2500 psi	Media	n/a
Product Type	Aluminum Pump w/bearing sleeve, fixed displacement	Rated Speed	500 to 4000 RPM
Maximum Continuous Pressure	172.0 bar	Flow Rate	n/a
Filter Efficiency Rating	Maintain SAE Class 4	Pump Type	Gear
Operating Temperature	-40 to 185 °F	Weight	2 to 3 lb
Maximum Displacement	0.641 inch3/rev	Maximum Operating Pressure	2500 psi
Body Material	Aluminum
