149F-4-4 - Brass 45° Flare Fittings

Name: 149F-4-4 - Brass 45° Flare Fittings
SKU: 149F-4-4
Price: 4.96 USD
Availability: InStock

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:

96 in stock

Olivette, MO	53
Decatur, IL	30
Kansas City, KS	9
Joplin, MO	2
Olivette, MO	2

Partner Available:

679 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 149F-4-4

$4.96/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 2 Type	Male Pipe
Connection 1 Type	Flare	Connection 1 Thread Size	7/16-20 inch
Connection 1 Tube Outside Diameter	1/4 inch	Product Style	Flare to Pipe
Connection 3 Tube Outside Diameter	NA	Shape	90° Forged Elbow
Connection 3 Type	NA	Connection 2 Thread Size	1/4 inch
Connection 3 Thread Size	NA	Connection 2 Tube Outside Diameter	NA
Minimum Operating Temperature	-65 °F	Brand	Parker
Specifications Met	SAE J512, SAE J513	Maximum Operating Pressure	96.5 bar
O-Ring Material	Fluorocarbon	Nut Material	Brass
Body Material	Brass	Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines
Dimensional Weight	0.27594424460431655 lb	Division	Fluid System Connectors Division
Division	Fluid System Connectors Division	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Technology	Fluid & Gas Handling	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Maximum Operating Temperature	250 °F
