155F-3 - Brass 45° Flare Fittings

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 61 days
Partner Available:	Backordered

SKU 155F-3

$19.54/each

Products specifications

Attribute name	Attribute value
UOM	EA	Product Style	Flare to Flare
Connection 1 Type	Flare	Connection 2 Type	Flare
Connection 1 Thread Size	3/8-24 inch	Connection 2 Thread Size	3/8-24 inch
Connection 1 Tube Outside Diameter	3/16 inch	Connection 2 Tube Outside Diameter	3/16 inch
Connection 3 Tube Outside Diameter	NA	Shape	90° Forged Elbow
Connection 3 Type	NA	Connection 3 Thread Size	NA
Minimum Operating Temperature	-53 °C	Brand	Parker
Specifications Met	SAE J512, SAE J513	Body Material	Brass
Maximum Operating Pressure	1,900 psi	Nut Material	Brass
O-Ring Material	Fluorocarbon	Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines
Division	Fluid System Connectors Division	Division	Fluid System Connectors Division
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Technology	Fluid & Gas Handling	Maximum Operating Temperature	121 °C
