166FSV-12-12 - Brass 45° Flare Fittings

Name: 166FSV-12-12 - Brass 45° Flare Fittings
SKU: 166FSV-12-12
Price: 61.52 USD
Availability: LimitedAvailability

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:

3 in stock

Springfield, MO	2
WICHITA, KS	1

Partner Available:

34 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 166FSV-12-12

$61.52/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 1 Type	Flare
Connection 3 Tube Outside Diameter	NA	Connection 3 Type	NA
Connection 1 Thread Size	1-1/16-14 inch	Connection 2 Thread Size	3/4 inch
Connection 3 Thread Size	NA	Connection 1 Tube Outside Diameter	3/4 inch
Connection 2 Tube Outside Diameter	NA	Connection 2 Type	NPT Swivel Nut
Shape	90° Swivel Elbow	Product Style	Flare to Female Flare Swivel
Division	Fluid System Connectors Division	Nut Material	Brass
Body Material	Brass	Maximum Operating Pressure	193 bar
O-Ring Material	Fluorocarbon	Maximum Operating Temperature	250 °F
Division	Fluid System Connectors Division	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Technology	Fluid & Gas Handling
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Brand	Parker
Specifications Met	SAE J512, SAE J513	Minimum Operating Temperature	-65 °F
