166FSV-6-6 - Brass 45° Flare Fittings

Name: 166FSV-6-6 - Brass 45° Flare Fittings
SKU: 166FSV-6-6
Price: 16.71 USD
Availability: LimitedAvailability

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:

2 Limited Stock

Springfield, MO

Partner Available:

175 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 166FSV-6-6

$16.71/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 1 Type	Flare
Connection 1 Thread Size	5/8-18 inch	Connection 1 Tube Outside Diameter	3/8 inch
Connection 3 Tube Outside Diameter	NA	Connection 3 Type	NA
Connection 2 Thread Size	3/8 inch	Connection 3 Thread Size	NA
Connection 2 Tube Outside Diameter	NA	Connection 2 Type	NPT Swivel Nut
Shape	90° Swivel Elbow	Product Style	Flare to Female Flare Swivel
O-Ring Material	Fluorocarbon	Maximum Operating Pressure	1,000 psi
Dimensional Weight	0.5518884892086331 lb	Specifications Met	SAE J512, SAE J513
Brand	Parker	Application	Pumps, Gas Grills, Coffee Makers, Adapters
Body Material	Brass	Division	Fluid System Connectors Division
Nut Material	Brass	Technology	Fluid & Gas Handling
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Maximum Operating Temperature	121 °C	Division	Fluid System Connectors Division
Minimum Operating Temperature	-53 °C

Customers who bought this item also bought

166FSV-8-8 - Brass 45° Flare Fittings
