249F-6-2 - Brass 45° Flare Fittings

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 9 days
Partner Available:	14 in stock

SKU 249F-6-2

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 2 Type	Male Pipe
Connection 1 Type	Flare	Connection 1 Thread Size	5/8-18 inch
Connection 1 Tube Outside Diameter	3/8 inch	Product Style	Flare to Pipe
Connection 3 Tube Outside Diameter	NA	Connection 3 Type	NA
Connection 2 Thread Size	1/8 inch	Connection 3 Thread Size	NA
Connection 2 Tube Outside Diameter	NA	Shape	90° Extruded Elbow
Minimum Operating Temperature	-65	Brand	Parker
Maximum Operating Temperature	250	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Technology	Fluid & Gas Handling
Body Material	Brass	Division	Fluid System Connectors Division
Division	Fluid System Connectors Division	Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines
Specifications Met	SAE J512, SAE J513	Maximum Operating Pressure	1,000
O-Ring Material	Fluorocarbon	Nut Material	Brass
