256F-4-2 - Brass 45° Flare Fittings

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 5 days
Partner Available:	Backordered

SKU 256F-4-2

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 1 Type	Flare
Connection 2 Type	Flare	Connection 1 Thread Size	7/16-20 inch
Connection 1 Tube Outside Diameter	1/4 inch	Product Style	Flare to Pipe
Connection 3 Type	Male Pipe	Connection 3 Thread Size	1/8 inch
Connection 3 Tube Outside Diameter	NA	Connection 2 Thread Size	1/4 inch
Connection 2 Tube Outside Diameter	NA	Shape	Adapter Tee
Division	Fluid System Connectors Division	Division	Fluid System Connectors Division
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Maximum Operating Pressure	1,400 psi
O-Ring Material	Fluorocarbon	Nut Material	Brass
Body Material	Brass	Specifications Met	SAE J512, SAE J513
Minimum Operating Temperature	-53 °C	Brand	Parker
Maximum Operating Temperature	250 °F	Technology	Fluid & Gas Handling
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
