2GF-12 - Brass 45° Flare Fittings

Name: 2GF-12 - Brass 45° Flare Fittings
SKU: 2GF-12
Price: 5.34 USD
Availability: InStock

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:

4 in stock

Kansas City, KS

Partner Available:

26 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 2GF-12

$5.34/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 1 Type	Flare
Connection 3 Tube Outside Diameter	NA	Product Style	Flare
Connection 2 Type	NA	Connection 3 Type	NA
Connection 2 Thread Size	NA	Connection 3 Thread Size	NA
Connection 1 Tube Outside Diameter	3/4 inch	Connection 2 Tube Outside Diameter	NA
Connection 1 Thread Size	NA	Shape	Flare Gasket
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Specifications Met	SAE J512, SAE J513
Brand	Parker	O-Ring Material	Fluorocarbon
Maximum Operating Pressure	193 bar	Minimum Operating Temperature	-53 °C
Maximum Operating Temperature	121 °C	Division	Fluid System Connectors Division
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Technology	Fluid & Gas Handling	Nut Material	Brass
Body Material	Brass	Division	Fluid System Connectors Division
