664FHD-6-4 - Brass 45° Flare Fittings

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 36 days
Partner Available:	40 in stock

SKU 664FHD-6-4

$25.40/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Shape	Connector
Connection 2 Type	Male Pipe	Connection 1 Thread Size	5/8-18 inch
Connection 1 Tube Outside Diameter	3/8 inch	Connection 3 Tube Outside Diameter	NA
Connection 3 Type	NA	Connection 2 Thread Size	1/4 inch
Connection 3 Thread Size	NA	Connection 2 Tube Outside Diameter	NA
Product Style	Female Flare to Pipe	Connection 1 Type	Flare Nut
Division	Fluid System Connectors Division	Nut Material	Brass
Body Material	Brass	Maximum Operating Temperature	121 °C
Division	Fluid System Connectors Division	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Technology	Fluid & Gas Handling
Minimum Operating Temperature	-65 °F	Brand	Parker
Application	Adapters, Fuels, Natural Gas, Propane, Refrigerant Lines	Specifications Met	SAE J512, SAE J513
Maximum Operating Pressure	68.9 bar	O-Ring Material	Fluorocarbon
