245IFHD-4-2 - Brass Inverted Flare Fittings

Name: 245IFHD-4-2 - Brass Inverted Flare Fittings
SKU: 245IFHD-4-2
Price: 22.62 USD
Availability: LimitedAvailability

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Manufacturer: Parker

Availability:

1 Limited Stock

Springfield, MO

Partner Available:

Backordered

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 245IFHD-4-2

$22.62/each

Qty:

Products specifications

Attribute name	Attribute value
UOM	EA	Shape	Branch Tee
Connection 2 Thread Size (inch)	1/8	Connection 2 Tube O.D. (inch)	na
Connection 1 Tube O.D. (inch)	1/4	Connection 2 Style	Male Pipe
Connection 1 Style	Inverted Flare	Style	Flare to Pipe
Division	Fluid System Connectors Division	Application	Pumps, Brake Lines
Maximum Operating Pressure	1400 psi	Nut Material	Brass, Zinc Chromate Steel
Body Material	Brass	Specifications Met	SAE J512
Minimum Operating Temperature	-53 °C	Maximum Operating Temperature	121 °C
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
