41IFS-3 - Brass Inverted Flare Fittings

Name: 41IFS-3 - Brass Inverted Flare Fittings
SKU: 41IFS-3
Price: 0.78 USD
Availability: InStock

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Manufacturer: Parker

Availability:

6 in stock

Wichita, KS

Partner Available:

19 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 41IFS-3

$0.78/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection 2 Style	na
Connection 2 Thread Size (inch)	na	Connection 2 Tube O.D. (inch)	na
Connection 1 Tube O.D. (inch)	3/16	Connection 1 Style	Inverted Flare
Style	Flare	Shape	Zinc Nut
Maximum Operating Pressure	131 bar	Nut Material	Brass, Zinc Chromate Steel
Body Material	Brass	Division	Fluid System Connectors Division
Maximum Operating Temperature	121 °C	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon	Minimum Operating Temperature	-65 °F
Application	Pumps, Brake Lines	Specifications Met	SAE J512
