*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

C5V10630B1

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 80 days
Partner Available:	Backordered

SKU C5V10630B1

$1,189.44/each

Products specifications

Attribute name	Attribute value
UOM	EA	Port Connection	SAE 1 1/4
Operation Type	Direct	Maximum Flow Rate	400 lpm
Cracking Pressure	0.5 bar	Material	Cast Iron
DIN Flange Size	SAE62	Connection Type	Flange
Actuation Type	Mechanical	Mounting Option	Flanged According Sae
Minimum Operating Temperature	-20 °C	Maximum Operating Temperature	60 °C
Seal Material	NBR	Product Series	Check Valve
