CM3BBV - CHECK SANDWICH VALVE - CM SERIES

Parker’s CM series check valves is an integral, full flow check valve.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 115 days
Partner Available:	Backordered

SKU CM3BBV

$619.08/each

Products specifications

Attribute name	Attribute value
UOM	EA	Mounting Type	Subplate
Maximum Flow Rate	30 GPM	Maximum Operating Pressure	5000 PSI
Size	NFPA D05; CETOP 5; NG10	Product Style	Sandwich Check Valve
Minimum Operating Temperature	-4	Mounting Type	Subplate
Port Connection	B Port Check	Actuation Type	Hydraulic Pressure
Maximum Operating Pressure	5000	Body Material	Steel
Weight	3.9	Maximum Operating Temperature	+140
Size	NFPA D05	Division	Hydraulic Valve Systems Division
Maximum Flow Rate	30	Seal Material	Fluorocarbon
Cracking Pressure	5	Media	Oil

Product resources

Literature and Reference Materials

CM Product Series catalog pages (PDF)
Parker Sandwich Valves Product catalog pages (PDF)
CATALOGUE - Direct operated check valve series CM (PDF)
MSG14-2500/US Industrial Hydraulic Valves (PDF)
