CB03AA30NA - Counterbalance Sandwich Valve - CB Series

Parker’s CB series counterbalance valve controls the actuator movement with overrunning loads.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 194 days
Partner Available:	Backordered

SKU CB03AA30NA

$677.88/each

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Operating Pressure	3000 PSI
Size	NFPA D03; CETOP 3; NG6	Mounting Type	Subplate
Maximum Flow Rate	15 GPM	Mounting Type	Subplate
Port Connection	A Port	Actuation Type	Hydraulic Pressure
Filter Efficiency Rating	ISO 4406 18/16/13 (meet NAS 1638:7)	Body Material	Steel
Weight	0.3 kg	Maximum Operating Pressure	207 bar
Pilot Pressure Ratio	3:01	Size	CETOP 3
Maximum Operating Temperature	176 °F	Division	Hydraulic Valve Systems Division
Maximum Flow Rate	57 L/min	Seal Material	Nitrile
Allowable Circuit Leakage	5 DPM	Media	Oil
Product Style	Counterbalance Valve	Minimum Operating Temperature	-4 °F
