CB05DD30ND - Counterbalance Sandwich Valve - CB Series

Parker’s CB series counterbalance valve controls the actuator movement with overrunning loads.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 194 days
Partner Available:	Backordered

SKU CB05DD30ND

$2,305.80/each

Products specifications

Attribute name	Attribute value
UOM	EA	Size	NFPA D05; CETOP 5; NG10
Mounting Type	Subplate	Maximum Flow Rate	30 GPM
Maximum Operating Pressure	5000 PSI	Port Connection	A and B Port
Mounting Type	Subplate	Actuation Type	Hydraulic Pressure
Filter Efficiency Rating	ISO 4406 18/16/13 (meet NAS 1638:7)	Maximum Operating Pressure	345 bar
Weight	6.4 lb	Body Material	Steel
Pilot Pressure Ratio	3:01	Division	Hydraulic Valve Systems Division
Maximum Flow Rate	114 L/min	Maximum Operating Temperature	176 °F
Size	NFPA D05	Seal Material	Nitrile
Allowable Circuit Leakage	5 DPM	Media	Oil
Minimum Operating Temperature	-4 °F	Product Style	Counterbalance Valve
