1543-40-40 - Crimp Style Hydraulic Hose Fitting - 43 Series Fittings

Parker’s best-selling 43 Series crimp style hydraulic fittings are a complete range of cost-effective, permanent, crimp-style hydraulic hose fittings for use with the Parkrimp family of crimpers.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	11 in stock

SKU 1543-40-40

$298.43/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Shape	Straight
Hex Type	n/a	Hose I.D. (size)	-40
Port Connection	2-1/2"	Materials of Construction	Steel
Product Style	SAE Code 61 Flange Head	Materials of Construction	Steel
Back-Up Hex Size	n/a	Division	Hose Products Division
Shape	Straight	Banjo Port Diameter	n/a
Nut Hex Size	n/a	Port Size	2-1/2 mm
Connection Size	n/a	Hose Inside Diameter	2-1/2 inch
Disclaimer	The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met. The u	Flange Size	n/a
Product Style	SAE Code 61 Flange Head

Product resources

Compliance, Certifications & Safety

Safety Guide--B.1 (PDF)

Literature and Reference Materials
