| UOM | EA | Seal Material | Nitrile |
| Configuration | Normally Closed | Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR |
| Override Functionality | Non-Detented | Flow Rate | 0.9, 1.4 GAL/MIN, 3.4, 5.3 L/MIN |
| Division | Hydraulic Systems Division | Operating Temperature | -30 to +250 °F |
| Flow Rate | 0.9, 1.4 Gal/min | Actuation Type | Electrical, Manual |
| Maximum Flow Rate | 3.4, 5.3 L/min | Power Consumption | 14, 19 W |
| Maximum Operating Pressure | 350 bar | Maximum Operating Temperature | +121 °C |
| Minimum Operating Temperature | -30 °F | Body Material | N/A |
| Seal Material | Nitrile | Weight | 0.34 lb |
| Operation Type | Solenoid operated, Manually operated | Current | 1.15 @ 12 VDC, 1.58 @ 12 VDC, 0.58 @ 24 VDC, 0.79 @ 24 VDC A |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Configuration | Normally Closed |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Hysteresis | Less than 6% |
| Frequency | 100-400 Hz | Function | Proportional Directional Control |
| Coil Type | 1/2" Super Coil | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Leak Rate | 10 @ 3000 PSI (210 BAR) cm3/min | Cavity Size | C08-4 |
| Valve Material | All parts steel. All operating parts hardened steel | Installation Torque | 30 Nm |
| Maximum Inlet Pressure Rating | 5000 psi | Override Functionality | Non-Detented |
| Response Time | 50 ms | Flow Rate Accuracy | +/- 15% @ 75% Nominal Current and Constant DeltaP Maintained with Pressure Compensator |
| Maximum Tank Pressure | 3000 psi | Coil Nut Tightening Torque | 3 lb-ft |
| Variation of Opening Point | 25% - 30% of Input Signal | | |
