DT2366

Manufacturer: Graco

Availability:	Backordered Estimated Lead Time: 10 days
Partner Available:	Backordered

SKU DT2366

Products specifications

Attribute name	Attribute value
UOM	EA	Ball Material	Santoprene
Weight	35 lb	Maximum Flow Rate	100 GPM
Series	1590	Material	Polypropylene
Seat Material	Stainless Steel	Air Exhaust Port Thread Gender	Female
Connection Type	Threaded	Type	Pneumatic
Air Inlet Thread Gender	Female	Diaphragm Compatible Material	Santoprene
Air Inlet Thread Type	NPT	Fluid Inlet Size	1-1/2 Inch
Air Exhaust Port Size	3/4 Inch	Center Section Material	Stainless Steel
Model	Husky	Air Inlet Size	1/2 Inch
Maximum Air Consumption	125 SCFM	Air Exhaust Port Thread Type	NPT
Maximum Cycle Rate	200 CPM	Maximum Solid Size	0.1875 Inch
Fluid Outlet Thread Type	NPT	Manifold Configuration	End Port
Fluid Outlet Thread Gender	Female	Fluid Inlet Thread Type	NPT
Diaphragm Material	Santoprene	Maximum Operating Temperature	150 deg F
Fluid Inlet Thread Gender	Female	Fluid Outlet Size	1-1/2 Inch
