FS-252-4FB - Flat Face, Chemical Compatible Quick Couplings - FS Series

Parker's stainless steel non-spill, flat face hydraulic couplers are ideal for use in applications where chemical or corrosive fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 36 days
Partner Available:	Backordered

SKU FS-252-4FB

$224.14/each

Products specifications

Attribute name	Attribute value
UOM	EA	Coupling Half	Male Nipple
Body Size (inch)	1/4	Connection Thread Size (inch)	1/4 - 18
Connection Type	Female BSPP	Application	Fluid Transfer
Flow Rate	3 Gal/min	Product Type	Push to Connect
Hex Size	1 inch	Minimum Operating Temperature	-15 °F
Division	Quick Coupling Division	Valve Type	Non-spill
Seal Material	Fluorocarbon	Maximum Operating Temperature	400 °F
Maximum Operating Pressure	2000 psi	Body Material	Stainless Steel 316
