FS1200S-V - Flow Control, Subplate Mounted Valve – FS Series

Parker’s FS series flow control valve offers superior construction and high versatility due to its variety of materials, sizes and port styles. It can be used in both the mobile and industrial markets.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 98 days
Partner Available:	Backordered

SKU FS1200S-V

$4,070.64/each

Products specifications

Attribute name	Attribute value
UOM	EA	Size	3/4"
Mounting Type	Subplate	Maximum Flow Rate	25 GPM
Maximum Operating Pressure	3000 PSI	Cracking Pressure	5 psi
Minimum Operating Temperature	N/A	Needle Type	Standard
Maximum Flow Rate	25 Gal/min	Division	Hydraulic Valve Systems Division
Maximum Operating Temperature	N/A	Seal Material	Fluorocarbon
Connection Size	3/4 inch	Function	Flow Control
Weight	1.17 kg	Body Material	Steel
Connection Type	Subplate mounting	Flow Rate	N/A
Actuation Type	Manual	Configuration	N/A
Maximum Operating Pressure	3000 psi

Product resources

Literature and Reference Materials

CATALOGUE - Throttle Check Valve Series FS (Europe and Asia) (PDF)
