FS1600S - Flow Control, Subplate Mounted Valve – FS Series

Parker’s FS series flow control valve offers superior construction and high versatility due to its variety of materials, sizes and port styles. It can be used in both the mobile and industrial markets.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 98 days
Partner Available:	Backordered

SKU FS1600S

$7,492.00/each

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Flow Rate	40 GPM
Maximum Operating Pressure	3000 PSI	Mounting Type	Subplate
Size	1"	Seal Material	Nitrile
Cracking Pressure	5 psi	Function	Flow Control
Connection Size	1 inch	Connection Type	Subplate mounting
Maximum Flow Rate	40 Gal/min	Division	Hydraulic Valve Systems Division
Maximum Operating Temperature	N/A	Configuration	N/A
Actuation Type	Manual	Weight	2.31 kg
Maximum Operating Pressure	3000 psi	Body Material	Steel
Minimum Operating Temperature	N/A	Needle Type	Standard
Flow Rate	N/A

Product resources

Literature and Reference Materials

CATALOGUE - Throttle Check Valve Series FS (Europe and Asia) (PDF)
