10356-12-12 - Global Fittings - 56 Series - Inch

Name: 10356-12-12 - Global Fittings - 56 Series - Inch
SKU: 10356-12-12
Price: 46.97 USD
Availability: InStock

The Global 56 Series replaces the 55/58 Series. It is shorter, more compact, and is 20% lighter than comparable fittings.

Manufacturer: Parker

Availability:

3 in stock

Springfield, MO

Partner Available:

4 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 10356-12-12

$46.97/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Materials of Construction	Steel
Hose I.D. (inch)	0.75"	Product Style	Male JIC 37° - Rigid - Straight
Length (inch)	3.07"	Connection 2 Size	1-1/16"-12
Tube Outside Diameter	n/a	Brand	Parker
Hex Size 1	n/a	Configuration	Hose to Port
Application	Construction Equipment	Dimensional Weight	0.0793 lb
Fitting Length	78 mm (see drawing legend A)	Maximum Operating Pressure	5000 psi (Dependent on hose)
Shipping Weight	0.181 kg	Connection 1 Type	Hose
Body Material	Steel	Industry	Industrial Manufacturing Equipment
Division	Parflex Division	Shape	Straight
Division	Parflex Division	For Fluid Type	Air (Pneumatic Media)
Coating	Chromium 6 Free-plated	Connection 2 Size	1-1/16"-12 inch Thread
Connection Length	1-3/4 inch Cut-off allowance	Technology	Fluid & Gas Handling
Connection 1 Size	19.05 mm Hose I.D.	Hex Size	1-1/8 inch (see drawing legend H)
Connection 2 Type	JIC 37°	Hex Size 2	n/a
