Picture of 10656-4-3 - Global Fittings - 56 Series - Inch

*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

10656-4-3 - Global Fittings - 56 Series - Inch

The Global 56 Series replaces the 55/58 Series. It is shorter, more compact, and is 20% lighter than comparable fittings.
Manufacturer: Parker
Availability:
277 in stock
Kansas City, KS148
TOPEKA, KS63
Olivette, MO19
Springfield, MO16
Decatur, IL14
Wichita, KS6
Peoria, IL6
Joplin, MO5
Partner Available:2206 in stock
Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.
SKU 10656-4-3
$9.51/each
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Products specifications
Attribute nameAttribute value
UOMEAMaterials of ConstructionSteel
Product StyleFemale JIC 37° - Swivel - StraightHose I.D. (inch)0.188"
Connection 2 Size7/16"-20Length (inch)1.78"
For Fluid TypeAir (Pneumatic Media)Connection 2 Size7/16"-20 inch Thread
CoatingChromium 6 Free-platedDivisionParflex Division
Connection Length1-1/16 inch Cut-off allowanceTechnologyFluid & Gas Handling
Connection 1 Size4.8 mm Hose I.D.Connection 2 TypeJIC 37°
Hex Size 19/16 inch (see drawing legend J)Hex Size 2n/a
Tube Outside Diametern/aHex Size9/16 inch (see drawing legend H)
ApplicationIndustrial HydraulicsBrandParker
Connection 1 TypeHoseDimensional Weight0.0214 lb
ConfigurationHose to PortMaximum Operating Pressure34.5 MPa (Dependent on hose)
Shipping Weight0.031 kgBody MaterialSteel
DivisionParflex DivisionShapeStraight
Fitting Length1.78 inch (see drawing legend A)IndustryIndustrial Manufacturing Equipment
Customers who bought this item also bought
Picture of 10356-4-3 - Global Fittings - 56 Series - Inch
