10656-6-6 - Global Fittings - 56 Series - Inch

Name: 10656-6-6 - Global Fittings - 56 Series - Inch
SKU: 10656-6-6
Price: 11.65 USD
Availability: InStock

The Global 56 Series replaces the 55/58 Series. It is shorter, more compact, and is 20% lighter than comparable fittings.

Manufacturer: Parker

Availability:

347 in stock

Olivette, MO	114
Kansas City, KS	94
Springfield, MO	46
Decatur, IL	32
Wichita, KS	25
TOPEKA, KS	18
Joplin, MO	10
COLUMBIA, MO	4
Peoria, IL	4

Partner Available:

5602 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 10656-6-6

$11.65/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Materials of Construction	Steel
Product Style	Female JIC 37° - Swivel - Straight	Hose I.D. (inch)	0.375"
Length (inch)	2.22"	Connection 2 Size	9/16"-18
Technology	Fluid & Gas Handling	Connection 2 Type	Swivel
Hex Size 2	n/a	Hex Size	9/16 inch (see drawing legend H)
Connection 1 Size	9.5 mm Hose I.D.	Hex Size 1	11/16 inch (see drawing legend J)
Tube Outside Diameter	n/a	Brand	Parker
Application	Industrial Hydraulics	Dimensional Weight	0.0214 lb
Connection 1 Type	Hose	Body Material	Steel
Maximum Operating Pressure	5000 psi (Dependent on hose)	Configuration	Hose to Port
Shipping Weight	0.13 lb	Shape	Straight
Division	Parflex Division	Fitting Length	2.22 inch (see drawing legend A)
For Fluid Type	Air (Pneumatic Media)	Industry	Off-road Machinery
Division	Parflex Division	Connection Length	32 mm Cut-off allowance
Connection 2 Size	9/16"-18 inch Thread	Coating	Chromium 6 Free-plated
