*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

H49AA1AA02100A - gpd H Model

Parker’s Aluminum Pump H Series fixed displacement gear pump offers high performance and high power density due to its aluminum construction.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 21 days
Partner Available:	Backordered

SKU H49AA1AA02100A

Products specifications

Attribute name	Attribute value
UOM	EA	Rotation	CounterClockWise
Shaft Seal Material	NBR	Options	n/a
Porting	UNF-2B SAE Striaght Thread: 1-5/16-12 Inlet - Rear, 3/4-16 Primary - Rear, 7/8-14 Secondary - Side	Shaft Type	Keyed w/1.56 Extension
Flow Rate (gpm)	n/a	Pressure Relief Valve	R/V returns to Pump Inlet Internal - Secondary Port External
Pump Displacement (cu in/rev)	H49: 1.178 (19.30 cc/rev)	Pressure Relief Setting (psig)	210 psi
Division	Pump & Motor Division	Product Type	Aluminum Pump w/bearing sleeve, fixed displacement
Operating Temperature	-42 to 85 °C	Media	n/a
Flow Rate	n/a	Maximum Flow Rate	n/a
Maximum Operating Pressure	172 bar	Body Material	Aluminum
Weight	2.3 to 3.2 kg	Mounting Type	2-Bolt SAE AA
Filter Efficiency Rating	Maintain SAE Class 4	For Fluid Type	Mineral Oil
Overall Length	7.24 inch	Displacement	36.5 cm3/rev
Direction of Rotation	Counterclockwise	Maximum Continuous Pressure	2500.0 psi
Maximum Kinematic Viscosity	Startup: 4000 SUS	Pump Type	Fixed
Maximum Displacement	2.227 inch3/rev	Rated Speed	500 to 4000 RPM
