7057-75304 - GST® II General Purpose Air & Water Hose

GST® II is a general purpose rubber hose designed for air compressor and shop air hose systems, transfer of mild/diluted chemicals, and water in applications to 212°F and 300 psi

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	2610 in stock

SKU 7057-75304

$3.60/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (inch)	3/4
Standard Pack Qty (ft)	350	Maximum Working Pressure (psi)	300
Color	Blue	Specifications Met	ARPM Class C Tube
Application	Multipurpose	Hose Reinforcement Material	4 Plies of Textile
Cover Material	Ethylene Propylene Diene Monomer (EPDM)	Minimum Operating Temperature	-40 °C
Minimum Bend Radius	6 inch	Cover Structure	Smooth
Cover Color	Blue	Weight	0.17 kg/m
Maximum Operating Pressure	20.7 bar	Inside Diameter	3/4 inch
Package Type	Reel	Outside Diameter	1.156 inch
Maximum Operating Temperature	212 °F	Compatible Fitting	HY Series
Division	Hose Products Division	Media	Mild Chemicals - Check your fluid compatibility with our catalogue chart.
Hose Inner Tube Material	ARPM Class C Oil Resistance	UOM	FT
Package Type	Reel	Inner Diameter	0.75 Inch
Working Pressure	300 PSI (20 bar)	Pkg Qty	400
Color	Blue	Pkg Qty/UOM	400 FT
Mating Fitting Series	HY	Inner Diameter Inch/mm	Inch
Parker Group	Fluid Connector	Inch/Metric	Inch
Mating End Fitting Series	HY	Color	Blue
Parker Division	Hose Products	Trade Name	GST® II
Series	7057	Hose Pressure Range	Low
Inner Diameter	0.75 Inch	Hose Category	Air & Multipurpose
