7181-501 - Heavy Duty Heater Hose, Series 7181

Name: 7181-501 - Heavy Duty Heater Hose, Series 7181
SKU: 7181-501
Price: 2.04 USD
Availability: InStock

Heavy Duty Heater Hose is designed for use in heater and radiator systems in vehicles and industrial equipment in applications to 257°F and 65 psi, Series 7181

Manufacturer: Parker

Availability:

237 in stock

Wichita, KS	137
Olivette, MO	100

Partner Available:

4875 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 7181-501

$2.04/foot

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (inch)	1/2
Maximum Working Pressure (psi)	65	Standard Pack Qty (ft)	500
Division	Hose Products Division	Application	Specialty
Media	Coolants	Maximum Operating Pressure	4.5 bar
Maximum Operating Temperature	125 °C	Minimum Operating Temperature	-40 °C
Specifications Met	SAE J20R3EC, Class D2	Weight	0.28 kg/m
Outside Diameter	20.7 mm	Cover Material	Ethylene Propylene Diene Monomer (EPDM)
Inside Diameter	12.7 mm	Compatible Fitting	n/a
Minimum Bend Radius	152.4 mm	Hose Inner Tube Material	Ethylene Propylene Diene Monomer (EPDM)
Hose Reinforcement Material	2 Plies of Textile	Cover Color	Black
Package Type	Reel

Product resources

Literature and Reference Materials
