SST-8 - High Flow, Unvalved, Hydraulic Quick Couplings - ST Series

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	6 in stock

SKU SST-8

$240.93/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Coupling Half	Female Coupler
Connection Type	Female NPTF	Body Material	303 Stainless Steel
Connection Thread Size (inch)	1 - 11 1/2	Maximum Operating Pressure	1700
Body Size (inch)	1	Body Material	Stainless Steel
Valve Type	Unvalved	Division	Quick Coupling Division
Maximum Operating Temperature	250 °F	Seal Material	Nitrile
Product Type	Push to Connect	Minimum Operating Temperature	-40 °F
Hex Size	1.75 inch	Flow Rate	50 Gal/min
Application	High Flow	Dimensional Weight	0.6232014388489209 lb

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
