SST-N6M - High Flow, Unvalved, Hydraulic Quick Couplings - ST Series

Name: SST-N6M - High Flow, Unvalved, Hydraulic Quick Couplings - ST Series
SKU: SST-N6M
Price: 63.99 USD
Availability: InStock

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Manufacturer: Parker

Availability:

3 in stock

Wichita, KS

Partner Available:

18 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU SST-N6M

$63.99/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Maximum Operating Pressure	3000
Connection Type	Male NPTF	Connection Thread Size (inch)	3/4 - 14
Coupling Half	Male Nipple	Body Material	303 Stainless Steel
Body Size (inch)	3/4	Maximum Operating Temperature	250 °F
Seal Material	n/a	Product Type	Push to Connect
Minimum Operating Temperature	-40 °F	Hex Size	1.06 inch
Plating Type	n/a	Application	High Flow
Flow Rate	28 Gal/min	Dimensional Weight	0.05341726618705036 lb
Body Material	Stainless Steel	Valve Type	Unvalved
Division	Quick Coupling Division

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
