SM-752-16FP - High Pressure, Hydraulic General Purpose Quick Couplings - SM Series

Name: SM-752-16FP - High Pressure, Hydraulic General Purpose Quick Couplings - SM Series
SKU: SM-752-16FP
Price: 87.76 USD
Availability: InStock

Parker's general purpose quick couplers and nipples are ideal for use in hydraulic applications where fluid lines require fast and easy connection and disconnection.

Manufacturer: Parker

Availability:

3 in stock

Kansas City, KS

Partner Available:

8 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU SM-752-16FP

$87.76/each

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Flow Rate	28 GAL/MIN
Maximum Operating Pressure	4500 PSI	Coupling Half	Male Nipple
Body Size (inch)	3/4	Connection Thread Size (inch)	1 - 11 1/2
Connection Type	Female NPTF	Product Type	Manual Connect
Plating Type	Zinc with clear trivalent chromate	Hex Size	1.62
Minimum Operating Temperature	-40 °F	Application	Hydraulic \|General purpose
Body Material	Steel	Valve Type	Poppet
Division	Quick Coupling Division	Maximum Operating Temperature	250 °F
Seal Material	Nitrile

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories (PDF)

Literature and Reference Materials
