787-32 - Hydraulic Constant Working Pressure Hose 5000 PSI - GlobalCore 787 Hose

Part of the GlobalCore family of robust hydraulic hoses. Parker’s 787 hose delivers 5000 PSI constant working pressure in a lightweight and easy to bend product.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 36 days
Partner Available:	41 in stock

SKU 787-32

$139.10/foot

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (size)	-32
Hose Cover Type	Standard Cover	Application	Petroleum Base Hydraulic Fluids
Minimum Bend Radius	318 mm	Specifications Met	ISO 18752, Type BC
Hose Reinforcement Material	4 or 6 Spirals of Steel Wire Compact	Cover Material	Synthetic Rubber
Minimum Operating Temperature	-40 °C	Outside Diameter	2.660 inch
Weight	4.37 lb/ft	Maximum Operating Pressure	350 bar
Inside Diameter	51 mm	Division	Hose Products Division
Size	-32	Media	Lubricants (Oils)
Maximum Operating Temperature	212 °F	Compatible Fitting	77 Series
Hose Inner Tube Material	Proprietary Synthetic Rubber Compound
