7212-381BL - JIFFY™ Push-On Multipurpose Oil Resistant Hose, Series 7212

Name: 7212-381BL - JIFFY™ Push-On Multipurpose Oil Resistant Hose, Series 7212
SKU: 7212-381BL
Price: 3.12 USD
Availability: InStock

Jiffy Push-On/Push Lock Oil Resistant Multipurpose Rubber Hose is designed to transfer air, mild chemicals, oil, water and refined fuels such as biodiesel, diesel, ethanol and gasoline in applications to 212°F and 300 psi, Series 7212.

Manufacturer: Parker

Availability:

2294 in stock

Springfield, MO	1,200
Olivette, MO	999
Joplin, MO	95

Partner Available:

9668 in stock

Quantities sourced from Partner Network will incur a 30% upcharge from the displayed price. Unit prices will be adjusted accordingly when these quantities are added to your cart.

SKU 7212-381BL

$3.12/foot

Qty:

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	FT	Hose I.D. (inch)	3/8
Color	Blue	Maximum Working Pressure (psi)	300
Standard Pack Qty (ft)	700	Minimum Operating Temperature	-40 °F
Minimum Bend Radius	3 inch	Cover Structure	Smooth
Cover Material	Chloroprene Rubber (CR)	Media	Fuels (Diesel) - Check fuel type with our catalogue chart.
Outside Diameter	15.7 mm	Package Type	Reel
Application	Push-On Hose	Hose Reinforcement Material	1 Braid of Textile
Specifications Met	MSHA	Cover Color	Blue
Maximum Operating Pressure	20.7 bar	Inside Diameter	3/8 inch
Vacuum Pressure Rating	28 Inch-Hg	Weight	0.18 kg/m
Design Factor	4:1	Maximum Operating Temperature	158 °F (Air)
Hose Inner Tube Material	Nitrile	Compatible Fitting	HY Series
Division	Hose Products Division
