CV-750-MFMF-5 - Modular, High Flow, Hydraulic In Line Check Valves - CV Series

Parker's, in line check valves are one way flow control devices used primarily in hydraulic systems to eliminate potential damage caused by fluid back pressure.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 42 days
Partner Available:	Backordered

SKU CV-750-MFMF-5

$194.80/each

Products specifications

Attribute name	Attribute value
UOM	EA	Outlet Port Size (inch)	1 1/16 - 12 UN
Inlet Port Connection Type	Male JIC 37 degree	Cracking Pressure (psi)	5
Body Size (inch)	3/4	Outlet Port Connection Type	Male JIC 37 degree
Inlet Port Size (inch)	1 1/16 - 12 UN	Mounting Type	Threaded
Seat Type	Metal Seal	Actuation Type	Mechanical
Configuration	n/a	Maximum Operating Pressure	3000 psi
Body Material	Steel	Connection Type	Male Flare JIC to Male Flare JIC
Maximum Operating Temperature	-40 °F	Division	Quick Coupling Division
Maximum Flow Rate	n/a	Connection Size	1-1/16"-12 UN inch
Seal Material	Metal	Flow Direction	n/a
Minimum Operating Temperature	250 °F
