NS-1002-16FO - Non-Spill, Flat Face, Push to Connect Quick Couplings with Sleeve Lock - NS Series

Parker's non-spill, flat face hydraulic couplers are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion.

Manufacturer: Parker

Availability:	Backordered Estimated Lead Time: 12 days
Partner Available:	3 in stock

SKU NS-1002-16FO

$253.05/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	Connection Thread Size (inch)	1 5/16 - 12
Body Size (inch)	1	Coupling Half	Male Nipple
Connection Type	Female ORB	Flow Rate	50 Gal/min
Application	Hydraulic	Body Material	Steel
Maximum Operating Pressure	2500 psi	Maximum Operating Temperature	250 °F
Seal Material	Nitrile	Valve Type	Non-spill
Division	Quick Coupling Division	Hex Size	1.62 inch
Plating Type	Zinc with clear trivalent chromate	Minimum Operating Temperature	-40 °F
Product Type	Push to connect
