942482Q - ParFit™ Interchange and Parker Replacement Element

Parker Original Hydraulic and Lube Oil Element and ParFit™ Competitive Interchange Replacement

Availability:	Backordered Estimated Lead Time: 45 days
Partner Available:	4 in stock

SKU 942482Q

$433.59/each

Bypass upcharge for backordered quantity

Products specifications

Attribute name	Attribute value
UOM	EA	UOM	EA
Efficiency βx(C) ≥ 1000	5 µ	Media	2 Micron Absolute
Collapse Pressure (psi)	150 psi	Efficiency βx(C) ≥ 200	4 µ
Seals	FKM: Fluorocarbon	Collapse Pressure (bar)	10.3 bar
Media Type	Microglass	Pkg Qty	1
Seals	FKM: Fluorocarbon	Collapse Pressure (psi)	150 psi
Media	2 Micron Absolute	B Dimension	0.555 in (14.1 mm)
Series	ParFit	Top Endcap Material	Mild steel
Parker Division	Hydraulic Filter	Glue Side Seam Adhesive	Epoxy
Bottom Endcap Material	Mild steel	Efficiency βx(C) ≥ 1000	5 µ
A Dimension	5.949 in (151.1 mm)	E Dimension	1.043 in (26.5 mm)
Media Composition Detail	Multilayer fiberglass with epoxy coated wire mesh on both sides	D Dimension	5.949 in (151.1 mm)
Parker Group	Filtration	C Dimension	0.555 in (14.1 mm)
Efficiency βx(C) ≥ 200	4 µ	Inner Support Cylinder Material	Stainless steel
Collapse Pressure (bar)	10.3 bar	Glue Endcaps Adhesive	Epoxy
Media Type	Microglass
